General:
- Type: Vaporizing haze generator
- Output volume: 0 – 2,500 m3 / minute (max)
- Continuous operation at full output: Yes
- Smoke projection: 0-45 degrees angle, adjustable
- Fluid consumption: 0 – 17.5 ml / min (1,050 ml / h max)
- Fluid capacity: 5L SmartBiB bag-in-box
- Fluid type: All Swefog Neutral-Pro water based fluids (SmartBiB)
- Heat-up time: 5 minutes
- Fan type: 108mm 70W high output air turbine
- DMX channels required: 2 (1st output, 2nd fan)
- Low fluid shutoff: At completely empty fluid bag
Electrical
- Mains voltage supply: 230V 50Hz
- Power consumption: 1,800W / 8A@230V
- Mains connector type: Neutrik PowerCon
Mechanical
- Weight (net): 15.5 kgs (w/o case)
- Weight (boxed): 27.5 kgs (with case, w/o fluid)
- Dimensions case w front & rear lids on: W540 x D660 x H220 m
